M30 Alarm Dialer
-
M30 Alarm Dialer
Auto Telephone Dialer Alarm System Wireless GSM
The M30 is an Auto Telephone Dialer alarm system that works wirelessly over the GSM mobile phone networks or can work over a standard PSTN land line phone system. The M30 has been purposely designed to work in harsh and hostile industrial conditions. and comes with all the types of feature you would expect from an industrial machine – including 4,8,16 & 56 separate inputs, over 24 hours of battery backup, an IP56 enclosure, Integrated mains failure detection plus many more.
Auto Telephone Dialer Alarm System Wireless GSM
Check out the features section below or visit the Standard Features and Optional Features pages for more information.
Wireless Communication
The M30 can send both wireless speech and SMS messages over the GSM mobile networks. The Speech side can be used as the main communication medium or as a backup device if required, each M30 comes with a standard PSTN landline connection, the M30 monitors the landline and if it fails automatically switch’s to the GSM networks.
The outgoing alarm messages are very easy to setup; While programming in your alarm contact telephone numbers you just select whether the recipient gets a Speech or an SMS message.
Messages
Each input on the M30 has its own dedicated Speech or SMS message plus there is a machine identifier. So instead of getting a “Channel 18 Alarm Condition”, you get a much more useful ” London Reservoir – High water level section B2″.
Alarm SMS Dialer Message Example
The Speech messages are fully user recordable via the Menu and LCD.
To make things easier for the end user we setup all the outgoing SMS messages to the users specification, this saves the user from typing in hundreds of characters.
If the user wants to change the SMS messages we just send out a replacement card that slots on the front.
The M30 Auto Telephone Dialer standard features include;
- 4, 8, 16 & 56 individual alarm inputs / channels.
- Individual Speech Messages for each input.
- Individual SMS Messages for each input.
- PSTN & GSM Options.
- Internal Mains Failure Alarm Sensor.
- 24+ Hour Internal Battery Backup.
- Fully Menu and Keypad Driven.
- IP56 Industrial Rated Enclosure.
Because the M30 is built by us in the UK if there are any special features you require for your project we can normally create them for you.
The above is only a small subset of the available features on the M30 Telephone Dialer; for a complete list visit the Standard Features and Optional Features pages or contact us for a quote.
Written by M30 GSM Alarm Dialer +
-
M30 Alarm Dialer
-
M30 Alarm Dialer
-
M30 Alarm Dialer
SMS Alarm Dialer
The M30 SMS Alarm Dialer is an rugged machine specifically designed for commercial and industrial conditions. It has over 60 years of alarm dialer design experience behind it and was designed with input from our customers to make sure it had all the features and functions they required.
SMS Alarm Dialer
The M30 SMS features include 4,8,16 or 56 individual inputs each with their own SMS or voice message, IP56 enclosure, integrated mains failure and 24+hrs battery backup to name a few (check out a more in-depth list below).
SMS features;
The SMS feature is very easy to setup, when you are setting up the outgoing alarm contact numbers you just select whether you would like the recipient to get an SMS or a voice message, the rest is done automatically for you.
Each individual input on the M30 has its own individual SMS message, plus there is a universal machine identification, so you can easily tell where it has come from.
So for example instead of getting a generic “Channel 32 Alarm Condition” SMS message you get a much more useful “London Desalination Plant – Low Water in tank 22″ message.
To make things easier for you we set up all the messages so you do not end up sitting there for hours typing in each
messageSpeech Messages;
If required you can also send voice messages to your alarm recipients, this can be over a standard PSTN lane line telephone or via the mobile GSM networks.
If you use the PSTN network you can setup the M30 to monitor the line and if it fails, to automatically switch to the GSM network to ensure you always get your alarms out.
As per the SMS messages each input can have its own individual speech message.
Software Features;
The M30 is designed and built by us in the UK and is fully customisable, so if you would like the M30 to work in a certain way or to have a unique function for your application then we will be happy to create it for you.
We also have lots of “off the shelf” upgrades available for example;
- More alarm numbers – As standard the M30 allows you to have up to 5 numbers in each roster (alarm contact list) but this can be extended to 10 or more.
- Auto Isolate – M30 automatically turns itself on and off at predefined times and days.
- Channel to Roster – Each input can dial a totally separate list of alarm contacts.
- Auto Test – The M30 will automatically make a test call on a predefined time and day.
Standard Features;
Below is a small subset of the standard features on the M30, for a more comprehensive list or information please contact us or visit the standard or optional features pages.
- 4,8,16 and 56 individual inputs/ channels.
- Individual user recordable speech and or SMS messages for each input.
- Voice, SMS, Pager alarm messages
- PSTN and or GSM phone network connection.
- Remote 247 Interrogation.
- Integrated Mains Failure detection.
- 24 Hour battery Backup
- Fully Menu and Keypad driven
- IP56 Industrial enclosure.
For more information of the SMS Alarm Dialer visit the SMS Feature page or the SMS section on our Blog.
Written by M30 GSM Alarm Dialer +
-
M30 Alarm Dialer
CTR Channel to Roster Software Upgrade
CTR Channel to Roster Software Upgrade
On a Standard M30 on when dialing it will select the Duty Roster set by the User (1,2 or 3). The current Duty Roster selected is shown on the top right of the LCD display (e.g. R1, R2, R3).
CTR Channel to Roster Software Upgrade
The Channel to Roster software works differently. When an alarm becomes active, instead of the M30 dialling out on one of the Duty Rosters, the M30 will automatically select a Roster linked to that alarm channel.
So for Example;
If Channel 1 is activated it will dial Roster 1.
If Channel 5 is activated it will dial Roster 5.
If Channel 10 is activated it will dial Roster 10 etc.
This software upgrade is great for when you need to communicate different alarms to different people for example the fire brigade for the fire alarm and the maintenance department for the Air Conditioning in the server room.
This new feature is available either as an option on a new M30 or as a simple software upgrade on a current machine.
For more information and pricing on the C2R Software Upgrade please contact us
Written by M30 GSM Alarm Dialer +
-
M30 Alarm Dialer
Fish Farm Alarm System
As fish farms are typically located in rural and remote locations we have designed our M30 along with our customers input to be the most robust and flexible system on the market. For example the M30 comes with 4 all the way to 56 separate alarm inputs, integrated 24hr plus battery backup, integrated mains failure and low battery alarms to name just a few – To see a full list look below or visit our Standard or Optional Features pages.
SMS
Alarm SMS Dialer Message Example
The M30 now comes with the option to send SMS text messages instead of or as well as voice messages. It is very easy to use, while setting up your M30 you simply select whether you would like the alarm message recipient to get an SMS or voice message.
Each input has its own user definable message plus there is a general machine identifier useful if you have more than one site. So for example instead of getting a “channel 1 alarm” you would receive a much more usefully “Windsor Fish Farm Low Water Alarm”.
PSTN and or GSM Phone networks
Because it can be difficult to get a PSTN landline to remote locations or get a cell \ mobile phone signal we have provided multiple connection options to the M30.
The M30 can connect to either a landline PSTN phone network or GSM mobile network or both to send voice alarm messages. If you choose to use both types, then the GSM network is used as a backup, so if the landline fails or is blocked it will automatically be swapped to the GSM network.
Software Upgrades
Fish Farm Alarm System
As the M30 is designed and built by us in the UK it is fully customisable, so if there is a special feature you would like or you would like it to work is particular way please let us know and we will normally be able to create it for you.
For example;
- More alarm numbers – As standard the M30 allows you to have up to 5 numbers in each roster but this can be extended to 10 or more.
- Auto Isolate – M30 automatically turns itself on and off at predefined times and days.
- Channel to Roster – Each input can dial a totally separate list of alarm contacts.
- Auto Test – The M30 will automatically make a test call at a predefined time and day.
Features Include
As an advanced alarm unit with over 50 years of design experience, the M30 comes with all the types of features you would expect, including free UK based phone support and on the road engineers for servicing, installation and upgrades.
The M30 comes with the following features;
- 4,8,16 & 56 individual alarm inputs.
- GSM or PSTN phone line connections.
- Real Speech Voice messages.
- SMS Text messages.
- Integrated battery backup.
- Fully menu and keypad driven.
- Remote interrogation.
For more information on our Fish Farm Alarm Systems, help or current pricing and availability please contact us or visit our standard features or auto dialler FAQs pages.
Written by M30 GSM Alarm Dialer +
-
M30 Alarm Dialer
SMS Auto Dialer
The M30 SMS Auto Dialer was purposely designed for use in harsh industrial environments and was designed with both our 50 plus years of experience and our customers input making it our most robust and feature rich unit to date. The M30 comes with a multitude of features including an IP56 enclosure, integrated battery backup and 4,8,16 or 56 separate inputs (check out more below).
SMS
Each input has its own individually definable SMS / Text Message, so instead of a “Channel 1 Alarm” you could receive a much more useful “Westbury Landfill – Mains Failure in building 2”.
When an alarm is activated the M30 will send an SMS for each active alarm to the preprogrammed recipient.
Voice (This feature can be ignored if not required.)
Each M30 also has the ability to send Voice alarm calls over PSTN and or GSM networks.
M30 Features;
The M30 comes with all the types of feature you would expect from an Advanced industrial unit,
SMS Auto Dialer
The M30 also comes with free UK based telephone support and engineers available for servicing, installation and upgrades.
Each M30 comes with the following features;
- 4,8,16 or 56 individual alarm inputs.
- SMS Text messages.
- GSM or PSTN phone line connections.
- Real Speech Voice messages.
- Integrated battery backup.
- Fully menu and keypad driven.
- Remote interrogation from any phone.
For more information on our SMS Alarm Systems, help or pricing please contact us or visit our standard features or auto dialer FAQs pages.
Written by M30 GSM Alarm Dialer +
-
M30 Alarm Dialer
Landfill Alarm System
We have been producing landfill alarm systems since 1958; all our systems are designed for use on both manned and unmanned sites.
Our M30 alarm system is an industrial machine that has been designed with our customers input over the last 50 years. It comes with all the features you would expect including 4 to 56 separ
ate inputs, battery backup, voice and SMS alarm messages and lighting / surge protection – check out more features below.The M30 is in use around the world for monitoring landfills by such companies as Viridor, Summerlease and various councils plus local authorities for protecting their active and closed Landfill sites. Typically they monitor such things as flare stack alarms, Gas alarms, engine failures, mains failures, lone worker alarms, water levels and tank levels etc but the list is endless.
PSTN
Each M30 comes with a PSTN landline connection; this can be used as your primary connection or ignored if you prefer to connect to the GSM networks to send voice and SMS alarm messages.
GSM
The GSM feature for voice on the M30 can be used in 2 ways, either as a dedicated connection for situations where you don’t have a landline PSTN connection, don’t want one or as a backup. When used as a backup the M30 monitors the connected PSTN line, if it fails or is cut the M30 will automatically switch to the GSM network to ensure you will always get the alarm message.
SMS
The M30 can send SMS as well as voice alarm calls over the GSM or PSTN networks. It is very easy to setup, when programming you just select whether the alarm recipient will get a SMS or voice call. Each input \ channel has its own dedicated customisable message so instead of a generic “Channel 1 alarm” you get a more useful “Flare Stack Bean Field Alarm” message.
Software Upgrades
As the M30 is designed an built by us in the UK it is fully customisable, so if there is a special feature you would like or you would like it to work is particular way please let us know and we will normally be able to create it for you.
For example;
Landfill Alarm System
- Auto Isolate – M30 automatically turns on and off at predefined times and days.
- Channel to Roster – each input can dial a totally separate list of alarm contacts.
- Auto Test – The M30 will automatically make a test call at a predefined time and day.
Features
As an advanced industrial unit made in the UK, the M30 comes with all the types of features you would expect, including free UK based phone support and on the road engineers for servicing, installation and upgrades.
The M30 comes with the following features;
- 4,8,16 & 56 individual inputs.
- GSM or PSTN phone line connections.
- Real Speech Voice messages.
- SMS Text messages
- Integrated battery backup.
- Fully menu and keypad driven.
- Remote interrogation.
For more information on our Landfill Alarm Systems, help or pricing please contact us or visit our standard features or auto dialler FAQs pages.
Written by M30 GSM Alarm Dialer +
-
M30 Alarm Dialer
Below are a round up of the latest Hints, Tips & Articles that we have posted about our M30 Alarm Autodialler during February 2014August 2013 Monthly Roundup
